Castle Creations Talon 90 25.2V 90A brushless ESC with a 20 amp peak, 9 amp continuous BEC. Built for extreme 500 and 550 class helis and sport 6S 600 setups, plus fixed wing aerobats up to 10 lbs (4.5 kg) and scale ships up to 20 lbs (9.07 kg). Castle Link compatible, order CSEM9999. One year limited warranty from purchase date. Doesn't cover abuse, neglect, incorrect wiring, over voltage or overloading. Includes: Talon 90 ESC with 10AWG battery wires, receiver connector, three 5.5mm male bullet motor connectors and instructions. Requires: a connector to match your battery. Specs: input 3-6S LiPo. Max continuous amperage at full throttle 90A (rated with 5 MPH airflow across the ESC). BEC user selectable 6 or 8V, 20A peak, 9A continuous. Size 1.7 x 3.14 x 0.7 inch (43 x 80 x 18mm), mounting bracket adds 2mm depth and 8mm width. Weight 3.0oz (84.5g) with 5.9 inch (150mm) power wires and no battery connectors. FITS: general hobby RC airplane brushless
