Home / Tamiya / Electric Motors / TAM53068

Sport Tuned Motor, Rs-540 Mabuchi - Tamiya
TAM53068

Sport Tuned Motor, Rs-540 Mabuchi - Tamiya

Tamiya Electric Motors
$30.99
In stock
Added ✓

30-day returns · Secure checkout by Stripe · We accept Visa, Mastercard, American Express, Discover, Apple Pay, Google Pay and Link

Whippy
Whippy checked a few minutes ago:
it's in stock.
- Lock it in

About this part

An economical, high-performance RS-540 sport tuned motor for on-road and off-road rigs. Plenty of Tamiya models will run it, but check your manual first.

Features

  • 2in leads with bullet connectors already installed
  • IN THE BOX:
  • One motor

Specifications

  • Operating voltage: 6-8.4V
  • Most efficient speed: 18,300rpm
  • Torque: 350g-cm at 18,300rpm
  • Peak speed: 21,000rpm
  • Peak current draw: 50A+
  • Motor shaft: 1/8in (some are labeled 3mm but are really the standard 1/8in)

Note

  • Can color is black or silver. The color is not up to us.
  • FITS:
  • HPI Electric RS4
  • Tamiya The Frog
  • Tamiya The Grasshopper
  • Tamiya CC-01 Truck
  • Tamiya CW-01
  • Tamiya DF-02

Fits

HPI Electric RS4Tamiya The FrogTamiya The GrasshopperTamiya CC-01 TruckTamiya CW-01Tamiya DF-02Tamiya DT-02Tamiya Lunch BoxTamiya M-03 MiniTamiya M-03LTamiya Stadium BlitzerTamiya TA-02SWTamiya Tamiya F1Tamiya TL-01Tamiya TT-01
